| 10/100 Port | 16 |
| Kasa Tipi | Rackmount |
| GIGABIT Port Sayısı | Yok |
| Combo Özelliği | Var |
| Poe Özelliği | Var 80W Max. | |
| Yönetilebilirlik | Yok |
| UPLINK / Bakır | 2X Gigabit RJ45 |
| SFP Girişi / UPLINK | 2X 1GB SFP UPLINK |
| Toplam Port Sayısı | 18 |
| Açıklama | Genel Özellikler Fiziksel Özellikler Interfaces • 16-port 10 / 100BASE-TX (8 ports support PoE) • 2 combo ports 10/100 / 1000BASE-T / SFP Standards • IEEE 802.3 10BASE-T • IEEE 802.3u 100BASE-TX • IEEE 802.3z • IEEE 802.3x flow control • IEEE 802.3az Energy-Efficient Ethernet (EEE) Switching matrix 7.2 Gbit / s Speed ??forwarding 64-byte packets 5,36 Mbits / s Switching Method Store-and-forward MAC-address table 8K Packet Buffer 384 KB Enhanced interface Automatic detection of polarity MDI / MDIX on all ports Indicators • On the device: Power • Per Port: Link / Act and Speed • On PoE-port: Power fail, Power OK Fan • 1 fan PoE standard IEEE 802.3af PoE-ports Ports 1-8, up to 15.4 watts per port PoE power budget 80 watts Static electricity ** up to 2 kV for ports 1-8 Physical parameters Dimensions 280 x 210 x 44 mm Weight 1.78 kg Power Power Input: 100-240 VAC, 50-60 Hz Power Consumption • Max. Power consumption: 102.6 W (PoE enabled), 14.3 W (PoE off) • Power consumption in standby mode: 7.1 W / 100 V; 8.3 W / 240 V Temperature • Operating: 0º to 40ºC • Storage: -40º to 70ºC Humidity • Operating: 0% to 95% (non-condensing) • Storage: 0% to 95% (non-condensing) MTBF (hours) • 395,864 hours Heat Dissipation • 349,9 BTU / h Certificates • FCC Class A • CE • CCC • RoHS • VCCI • BSMI • C-Tick Security • CB • cUL • LVD • CCC • BSMI |
| Model Link | Üretici Sayfası |
| Model Dosya | Ek Döküman |
