| 10/100 Port | 4 |
| Kasa Tipi | Rackmount |
| Toplam Port Sayısı | 6 |
| GIGABIT Port Sayısı | Yok |
| Poe Özelliği | 94W Max. Var | |
| Combo Özelliği | Yok |
| UPLINK / Bakır | 2X Gigabit RJ45 |
| SFP Girişi / UPLINK | Yok |
| Yönetilebilirlik | Var |
| Açıklama | Fiziksel Özellikler Hardware Interfaces • 4 ports 10/100Mbps with PoE • 2 10/100/1000BASE-T Indicators • Power/system (per device) • Link/activity/PoE/speed (per port) • Budget for PoE power Standards and protocols • Protocol IEEE 802.3 10base-T Ethernet (copper twisted pair) • IEEE 802.3 U for 100Base-TX fast Ethernet (copper twisted pair) • IEEE 802.3 AB 1000BASE-T Gigabit Ethernet (twisted-pair copper) • Ieee802.3af PoE • Ieee802.And 3at for PoE • Auto-negotiation • Flow control IEEE 802.3 x Case • Metal, width 7 inches Performance Switching matrix • 4.8 Gbps Switching technique • Store-and-forward Table MAC addresses • 4K entries The forwarding rate of packets • 3.6 million packets Buffer • 2,75 MB Flash memory • 2 MB Software Layer 2 features • Table of MAC addresses - 4K entries • Flow control - Flow control 802.3 x - Blocking prevention hol • Port mirroring - One-to-one - Many-to-one - Supports mirroring for inbound/ outbound/ traffic in both directions • Protocols Spanning Tree - 802.1 D STP 2004 edition - In RSTP 802.1 W - Root restriction (defined in 802.1 Q-2005) • Link aggregation 802.3 AD - Supports 2 trunking groups: - 2-4 port trunk, port, and port 1-4 5-6 Multicast layer 2 • IGMP snooping - IGMP v1, v2 and VLAN • Mode VLAN: port-based or tega Quality of service (QoS)for • 802.1 p • Max. 4 queues per port • Mechanisms Queuing Strict Cyclic weighted algorithm (wrr) • Bandwidth management • QoS based on: - 802.1 p - Field dscp - GS - the number of the TCP or udp port Safety • Protection from the storm • Binding Mac-port Physical parameters Sizes • 180 x 145 x 34 mm Weight • 480 g Conditions Food • External power adapter - Output: 54 In / 2,22 And Max. power consumption • 94,5 W Max. budget PoE • 80 watts Heat dissipation • 45,73 BTU/h Mean time to failure (hours) • 61320 The noise level • 0 dB Temperature • Operating: 0 to 50 °C • Storage: -20 to 70 °C Humidity • Operating: 20% to 80% non-condensing • Storage: 10% to 90% non-condensing The kit • Switch des-1100-06MP • Power adapter • Power cable • Clamp for power cable • Rubber feet (4 PCs.) • Quick installation guide • Warranty card • Sticker with serial number Other Certificates • CE |
