| 10/100 Port | 8 |
| Kasa Tipi | Rackmount |
| UPLINK / Bakır | Yok |
| GIGABIT Port Sayısı | Yok |
| Poe Özelliği | 140W Max. Var | |
| Combo Özelliği | Yok |
| Yönetilebilirlik | Yok |
| SFP Girişi / UPLINK | Yok |
| Toplam Port Sayısı | 8 |
| Açıklama | Genel Özellikler: Fiziksel Özellikler Technical Specifications General Standards • IEEE 802.3 10BASE-T Ethernet (twisted-pair copper) • ANSI/IEEE 802.3 NWay auto-negotiation • IEEE 802.3x flow control • IEEE 802.3u 100BASE-TX Fast Ethernet (twisted-pair copper) Ports • 8 10/100 Mbps PoE ports Switching Fabric • 1.6 Gbps switching fabric Data Transfer Rates • Ethernet • 10 Mbps (half duplex) • 20 Mbps (full duplex) • Fast Ethernet • 100 Mbps (half duplex) • 200 Mbps (full duplex) Media Interface Exchange • Auto MDI/MDIX adjustment for all ports Network Cables • 10BASE-T • UTP CAT 3/4/5/5e (100 m max.) • EIA/TIA-586 100-ohm STP (100 m max.) • 100BASE-TX • UTP CAT 5/5e (100 m max.) • EIA/TIA-568 100-ohm STP (100 m max.) LED Indicators • Per port: • Link/Activity • PoE Status • Per device: • Power • PoE Max 1 • PoE Max 2 Transmission Method • Store-and-forward MAC Address Table • 2K entries per device Packet Filtering/Forwarding Rates • Ethernet: 14,880 pps per port • Fast Ethernet: 148,800 pps per port RAM Buffer • 96 KB per device Physical & Environmental Dimensions • 11.02” x 7.05” x 1.75” (280mm x 179mm x 44.5mm) Heat Dissipation • Standby: • 22.67 BTU/h • Maximum: • 486.7 BTU/h Power Input • 100 to 240 VAC, 50/60 Hz, Internal Universal Power Supply Power Consumption • Standby: • 6.9W • Maximum: • 146W Weight • 3.6 lbs (1.65 Kg) Temperature • Operating: 32 to 104° F (0 to 40° C) • Storage: -40 to 158° F (-40 to 70° C) Humidity • Operating: 5% to 95% RH non-condensing • Storage: 5% to 95% RH non-condensing Certifications • FCC Class B • CE • RoHS • cUL Power over Ethernet PoE capable ports • Ports 1 - 8 PoE standard • IEEE 802.3af and IEEE 802.3at PoE power budget • 140W total • Ports 1-4: 70W • Ports 5-8: 70W Warranty Information Warranty • Limited Lifetime |
