| 10/100 Port | Yok |
| Poe Özelliği | 242W Max. Var | |
| Kasa Tipi | Rackmount |
| UPLINK / Bakır | Yok |
| Combo Özelliği | Yok |
| Yönetilebilirlik | Var |
| SFP Girişi / UPLINK | 2X 1GB SFP UPLINK |
| Toplam Port Sayısı | 10 |
| GIGABIT Port Sayısı | 8 |
| Açıklama | Genel Özellikler Hardware Version • B1 Size • 11-inch Desktop/Rackmount Size, 1U Height Number of Ports • 8 10/100/1000 Mbps PoE • 2 SFP 1000 Mbps Port Functions • IEEE 802.3 compliant • IEEE 802.3u compliant • IEEE 802.3ab compliant • IEEE 802.3af/802.3at compliant • IEEE 802.3bt draft/UPoE (DGS-1100-10MPP/26MPP only) • IEEE 802.3x Flow Control supports full-duplex mode • Supports manual/auto MDI/MDIX configuration • Auto-negotiation • Supports half/full-duplex operation • IEEE 802.3az compliant • Up to 6 kV surge protection per port Switching Capacity • 20 Gbps Maximum Forwarding Rate • 14.88 Mpps MAC Address Table Size • 16K Entries Packet Buffer • 1.5 MBytes Flash Memory • 16 MBytes PoE Standard • IEEE 802.3af/802.3at/802.3bt draft/UPoE PoE Capable Ports • Ports 1 to 8 PoE Power Budget • 242 watts (30 watts max. per PoE port for ports 1 to 8, 75 watts max. for ports 7 to 8) Standby Mode Power Consumption • 10.47 watts Maximum Power Consumption • 253 watts (PoE on) • 14.6 watts (PoE off) Power Input • 100 to 240 V AC • 50 to 60 Hz Internal Power Supply MTBF • 1, 719, 951 hours Acoustics • 53 dB(A) Heat Dissipation • 1001.12 BTU/hr Weight • 1.98 kg Dimensions • 280 x 180 x 44 mm Ventilation • 1 x Fan Operating Temperature -5 to 50 °C Storage Temperature -40 to 70 °C Operating Humidity 0% to 95% non-condensing Storage Humidity 0% to 95% non-condensing EMI FCC/IC, CE, VCCI, BSMI, CCC Safety cUL, UL, LVD, CB, CCC, BSMI VLAN • Port-based VLAN • 802.1Q tagged VLAN • Auto Surveillance VLAN • Voice VLAN • Management VLAN • Asymmetric VLAN • VLAN Group • Supports 128 static VLAN groups • Max. 4094 VIDs L2 Features • Flow Control • 802.3x Flow Control • HOL Blocking Prevention • Jumbo Frames up to 9216 Bytes • IGMP Snooping • IGMP v1/v2/v3 awareness Snooping • Supports 64 Groups • IGMP Snooping Querier • 802.3ad Link Aggregation: • DGS-1100-10MP: Support 5 groups per device and 8 ports per group • Ethernet Ring Protection Switching • G.8032 ERPS • Loopback Detection • Cable Diagnostics • LLDP • Port Mirroring • One-to-One • Many-to-One • Statistics • Tx Ok • Tx Error • Rx Ok • Rx Error • Spanning Tree Protocol • 802.1D STP • 802.1w RSTP • L2 Multicast • MLD Snooping Quality of Service (QoS) • 802.1p Quality of Service • 4 queues per port • Queue Handling • Strict • Weighted Round Robin (WRR) • Port-based Bandwidth Control (Rate Limiting) • Ingress: 8Kbps • Egress: 64Kbps Security • D-Link Safeguard • Traffic Segmentation • Broadcast/Multicast/Unknown Unicast Storm Control • DoS Attack Prevention • SSL Management • Web-based GUI (Supports IPv4/IPv6) • Client-based Utility (D-Link Network Assistant Utility) Green Technology • Power Saving by • Link Status • LED Shut-Off • Port Shut-Off • System Hibernation • Compliant with IEEE 802.3az Energy Efficient Ethernet MIB/RFC Standards • RFC768 UDP • RFC791 IP • RFC792 ICMP • RFC793 TCP • RFC826 ARP • RFC1213 MIB II • RFC1493 Bridage MIB • RFC1907 SNMPv2 MIB • RFC1215 MIB Traps Convention • RFC2233 Interface Group MIB • RFC2665 Ether-like MIB • RFC4363 IEEE 802.1p MIB • ZoneDefense MIB • Private MIB • RFC951 BootP client • RFC1542 BootP/DHCP client • RFC2236 IGMP Snooping |
| Model Dosya | Ek Döküman |
